Planning Anyone with cad fancy drawing me a fan grill.

Discussion in 'Modding' started by ricickle, 13 Oct 2009.

  1. ricickle

    ricickle Reamer

    Joined:
    27 Mar 2008
    Posts:
    218
    Likes Received:
    0
    Im looking for someone that dosent mind and has some free time to draw me up a fan grill in some sort of cad program, i would do it but all i have is my netbook justnow :grr:

    basicly im after a double 120mm radgrill with the ankah design from my project log as the grill design instead of the usual slots.
    Project log

    cheers

    ricickle, 13 Oct 2009
    #1
  2. stuartwood89

    stuartwood89 Please... Just call me Stu.

    Joined:
    20 Aug 2008
    Posts:
    1,566
    Likes Received:
    52
    If you can take a sketchup file I could give it a shot.

    Edit: Looks like free Sketchup can't export to something like .dxf unless you only want a .png or a .jpg, otherwise it'll have to be a .skp.

    Last edited: 14 Oct 2009
    stuartwood89, 13 Oct 2009
    #2
  3. ricickle

    ricickle Reamer

    Joined:
    27 Mar 2008
    Posts:
    218
    Likes Received:
    0
    can be a png or jpeg its just to get an idea of what it would look like
    then ill send it to tom for machining

    ricickle, 14 Oct 2009
    #3
  4. Interloper

    Interloper Faux Pro Modder

    Joined:
    17 Jul 2009
    Posts:
    89
    Likes Received:
    2
    Hmmmmm. let me play around a little bit and see if I can come up with something for you.

    Interloper, 14 Oct 2009
    #4
  5. ricickle

    ricickle Reamer

    Joined:
    27 Mar 2008
    Posts:
    218
    Likes Received:
    0
    Cheers for the help guys :D

    ricickle, 14 Oct 2009
    #5
  6. Interloper

    Interloper Faux Pro Modder

    Joined:
    17 Jul 2009
    Posts:
    89
    Likes Received:
    2
    What material are you going to be using?

    Also, can it extend beyond the size of the rad?

    Last edited: 14 Oct 2009
    Interloper, 14 Oct 2009
    #6
  7. ricickle

    ricickle Reamer

    Joined:
    27 Mar 2008
    Posts:
    218
    Likes Received:
    0
    either 3mm alu or 3mm plexi
    and yeah i could be aslong as it uses the 8 standard fan holes

    ricickle, 14 Oct 2009
    #7
  8. Interloper

    Interloper Faux Pro Modder

    Joined:
    17 Jul 2009
    Posts:
    89
    Likes Received:
    2
    Good, because I had it extend beyond the rad size. :D
    The holes are correct based off of MNPCTECH's website. Thanks Bill for having basic dimensions posted!:thumb:

    What I have now is a two piece grill, but it could easily be melded into a single piece if need be. Other modification suggestions welcome as well.

    Here's what I got:

    [​IMG]

    [​IMG]

    I forgot to add these, can do it if you want.[​IMG]

    Interloper, 15 Oct 2009
    #8
    ricickle likes this.
  9. ricickle

    ricickle Reamer

    Joined:
    27 Mar 2008
    Posts:
    218
    Likes Received:
    0
    woah thats awesome dude thanks
    +1 to you

    ricickle, 15 Oct 2009
    #9
  10. Interloper

    Interloper Faux Pro Modder

    Joined:
    17 Jul 2009
    Posts:
    89
    Likes Received:
    2
    No problem. Glad you like it.

    I'm kind of taken by this design. I think I'll tweak it a bit more, add the parts I left out. I'll merge it to one piece and see how it looks and I'll add mesh to the 2-piece design.

    Interloper, 15 Oct 2009
    #10
  11. ricickle

    ricickle Reamer

    Joined:
    27 Mar 2008
    Posts:
    218
    Likes Received:
    0
    Cheers dude your a star

    ricickle, 15 Oct 2009
    #11
