    Update no 26 guys and one step before the end!
    The only thing left before I finish this mod is some cable customization and management so
    my next update might be the final shots only.
    Lets move one with this update!
    First I realized that I painted the wrong side of the main compartments side panels, so I had to paint them again. I used black hammered paint for that technique.
    I also decided to use only one panel, the one on the top, as the second is useless as it will be used only in transportations.

    [​IMG]

    [​IMG]

    [​IMG]

    I used this sharp piece of acrylic to draw some lines.

    [​IMG]

    [​IMG]

    Last step pf this process is to add some random quick pass white lines over the black.

    [​IMG]

    Back to the assembly of this mod. Reservoir, fans, some cable management, uv cold cathodes etc.

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    I also found this UV led thingy and disassembled it for me to create something for the reservoir later on.

    [​IMG]

    I also had to create a cover for the GPU's bracket to cover a distance that was created due to the mods design and also add a different touch to it.
    I used 5mm white acrylic for that which I painted later on.
    I also tried to create a housing for the leds from 1mm acrylic which proved a fail in the process so I have to make something else!

    [​IMG]

    Testing the side panel.... again!

    [​IMG]

    [​IMG]

    For the mods main support I am not going to use the wooden rod which I created at the first place, but instead I used an aluminum angle which I painted hammer black.

    [​IMG]

    [​IMG]

    More assembly and testing shots.

    [​IMG]

    [​IMG]

    [​IMG]

    Sata power cable modification.

    [​IMG]

    My various connectors collection lol! :)

    [​IMG]

    Here I created a custom slimline sata power connector out of a normal sata power connector.
    I cut it in half after I removed the middle pin so it will left with only two pins ( 6 in the interior)

    [​IMG]

    [​IMG]

    Attached the first sata power in the proper distance.

    [​IMG]

    Second one attached too.

    [​IMG]

    And the slimline power connector mod finished and sleeved!

    [​IMG]

    [​IMG]

    I also sleeved the two main hdd sata cables.

    [​IMG]

    Here is the PCI-E cable. It comes with 2 sleeved cables 6+2 pins each.

    [​IMG]

    I had to sleeve them all to reduce the clutter and also make the cable more compact .

    [​IMG]

    [​IMG]

    I cut the cables in size and with the crimping tool I added new pins and later connectors.

    [​IMG]

    Some more random shots!

    [​IMG]

    [​IMG]

    [​IMG]

    I hope that you are going to like the "different approach" I used on this mod and the artistic touch.
    Through my mods I ve shown that I can go in any direction I want, factory style or artistic but I prefer to be and create something different instead of the usual "one way" styles.
    Thanks for your time guys and I really appreciate your feedback and support.
