Case Mod - In Progress "The Nehalem Apple" Completed! Update 06/19/09

Discussion in 'Project Logs' started by monkey120101, 9 Apr 2009.

?

What looks better with a 120mm at the front of the case?

  1. 3 Screws

    2 vote(s)
    7.4%
  2. 4 Screws

    10 vote(s)
    37.0%
  3. No fan, no screws

    15 vote(s)
    55.6%
  1. monkey120101

    monkey120101 My right hand is a Dremel.

    Joined:
    26 Nov 2008
    Posts:
    64
    Likes Received:
    0
    Here's a small update which consists of removing the fan and slightly improving the cabling by sticking the molex and sata power cables under the mobo tray.

    [​IMG]
    As you can see, the fan is there and the molex and sata cables are protruding at the top left corner of the motherboard tray.
    [​IMG]
    The naked case :blush: (cabling nightmare!!!)
    [​IMG]
    Much better! The fan is gone and the cables are tucked away nice and neatly under the motherboard tray.
    [​IMG]
    Just another view...

    Thanks for reading! Stay tuned :thumb:
    The next update will be tomorrow or after tomorrow when the heatsink arrives.

  2. Guest-23315

    Guest-23315 Guest

    I have to wonder why on earth you decapitated your heat-pipes...

    Seems like a nice way to fry a processor when you consider heat-pipes are supposed to be a closed unit.

    Otherwise... I like :thumb:

  3. MonkeyNutZ

    MonkeyNutZ Crysis Fiend

    Joined:
    5 Jun 2007
    Posts:
    150
    Likes Received:
    0
    I was thinking about building an Micro or Pico ITX PC in one of those external HDD cases, what are your thoughts on the build quality?

  4. monkey120101

    monkey120101 My right hand is a Dremel.

    Joined:
    26 Nov 2008
    Posts:
    64
    Likes Received:
    0
    Don't think that I did that for the hell of it lol. The heatpipes were the only things getting in the way of the heatsink fitting into the case, and because I was impatient and didn't want to cut the case I cut the heatpipes.

  5. monkey120101

    monkey120101 My right hand is a Dremel.

    Joined:
    26 Nov 2008
    Posts:
    64
    Likes Received:
    0
    Well....
    1. The powerbutton is blue when turned on, and mine came crooked although that isn't a problem because it's not that bad.
    2. The housing feels a little rough, as though it wasn't sanded enough.
    3. The inner casing has to be forced in when removing and replacing.

    Otherwise, it's an excellent housing. It's gorgeous and compliments the G5 quite nicely. I'd say go for it:

    1. The powerbutton's led can easily be dis-connected (if you know the pinout).
    2. It's not that rough, just a little grainy.
    3. A guess it's good that it's a tight fit; your components wont slide around.

  6. Teknokid

    Teknokid Well-Known Member

    Joined:
    6 Dec 2007
    Posts:
    1,095
    Likes Received:
    26
    you know chopping the top off the heatpipes breaks them? They have a vacuum inside which you would have broken...

  7. monkey120101

    monkey120101 My right hand is a Dremel.

    Joined:
    26 Nov 2008
    Posts:
    64
    Likes Received:
    0
    :read:

  8. Guest-23315

    Guest-23315 Guest

    He's making a good point though.. I understand why you did it, so that the cooler would fit in the case, but I don't think you understand the amount of damage you've done to the cooler..

    Its now useless, as it won't conduct heat properly so your CPU will fry.. If you don't want our advice, then I look forwards to seeing your new CPU.

  9. monkey120101

    monkey120101 My right hand is a Dremel.

    Joined:
    26 Nov 2008
    Posts:
    64
    Likes Received:
    0
    Now I know :duh: :wallbash:

  10. dark4181

    dark4181 Ero-sennin-tebayo

    Joined:
    3 Jan 2008
    Posts:
    168
    Likes Received:
    0
    And knowing is half the battle

    o_O

  11. Pieface

    Pieface Well-Known Member

    Joined:
    8 Mar 2009
    Posts:
    3,355
    Likes Received:
    134
    Live and learn I guess. Love the case though, look forward to seeing it done.

  12. BlackWhizz

    BlackWhizz New Member

    Joined:
    17 Jul 2008
    Posts:
    383
    Likes Received:
    1
    About the poll; i would mount some alu bars inside of the case and mount those fans on those alu bars. Not on that beautiful apple grey.

  13. Mokey Mokey

    Mokey Mokey New Member

    Joined:
    9 Mar 2009
    Posts:
    143
    Likes Received:
    2
    Yeah, absolutely the way to go.

  14. monkey120101

    monkey120101 My right hand is a Dremel.

    Joined:
    26 Nov 2008
    Posts:
    64
    Likes Received:
    0
    Update! 4/15/09

    The heatsink finally arrived! I'm glad to report the installation was a success! However, I hit a snag later on. Read more to find out:
    [​IMG]
    The box from Newegg.
    [​IMG]
    The new heatsink in all of its glory.
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    Well...it LOOKS like it's going to fit....
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    Installed! :clap:

  15. blackflag

    blackflag I Kill Dremels

    Joined:
    16 Oct 2003
    Posts:
    501
    Likes Received:
    16
    That heatsink looks nice. Matches the style nicely- even resembles the stock G5 heatsinks.

    What about the snag you mentioned? Did it end up fitting in the end, then, by switching RAM slots?

  16. monkey120101

    monkey120101 My right hand is a Dremel.

    Joined:
    26 Nov 2008
    Posts:
    64
    Likes Received:
    0
    A continuation! 4/15/09

    [​IMG]
    Motherboard inserted, looking good.
    [​IMG]
    Cables connected....again.
    [​IMG]
    More cables
    [​IMG]
    I didn't take any chances with the hole, and I was actually grateful I made the cut bigger because installing the fan was MUCH easier.
    [​IMG]
    Fan installed! :clap:
    [​IMG]
    Rear usb :blush:
    [​IMG]
    [​IMG]
    The fabled right angle dvi connector :rock:
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    Fan grill installed...
    [​IMG]
    Fans installed!!! The part I've been trying to accomplish for the past week! :clap::clap: :rock:

    This is where I hit the snag.... read on.
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    All installed quite nicely :D
    [​IMG]
    [​IMG]
    [​IMG]
    Lookin' good :D :rock:
    [​IMG]
    All closed up :D
    [​IMG]
    [​IMG]
    [​IMG]
    Rear cabling....
    [​IMG]
    And a top view.

    So, everything went extremely well. I thought I was finished... at least up until I hit the power button. Immediately, I was greeted with the sound of two EXTREMELY noisy fans. It wasn't the fans themselves, but an odd clicking noise (probably a rpm counter gone wrong). Anyway, I disconnected the two fans and am awaiting the arrival of two new, silent fans :rock:

    For the most part, it's done :D Thanks for reading, updates to come!
    :rock: :rock: :rock: :rock: :rock: :rock: :rock: :rock: :rock: :rock:

  17. monkey120101

    monkey120101 My right hand is a Dremel.

    Joined:
    26 Nov 2008
    Posts:
    64
    Likes Received:
    0
    Lol! You caught me mid update :D

  18. monkey120101

    monkey120101 My right hand is a Dremel.

    Joined:
    26 Nov 2008
    Posts:
    64
    Likes Received:
    0
    About the 120 mm front fans:
    I hardly think they're required. All of my temps are actually much lower than my old system, which had 5 120 mm fans. The system would Idle around 45, now around 37/39. Same decreases all around. I think this is due to the power supply's position; it's positioned practically right over the northbridge heatsinks, sucking away the hot air and the cpu fan pulls cool air from the front.
    CPU Stock Heatsink
    Idle: 32
    Load: 90
    New, Mugen Heatsink
    Idle: 22 (Room temp)
    Max Load: 72

  19. stonedsurd

    stonedsurd Is a cackling Yuletide Belgian

    Joined:
    11 Mar 2009
    Posts:
    7,767
    Likes Received:
    294
    Looks great.
    Will you be doing any exterior mods, or are you leaving it 'stock' looking?

  20. monkey120101

    monkey120101 My right hand is a Dremel.

    Joined:
    26 Nov 2008
    Posts:
    64
    Likes Received:
    0
    Def. stock.
