Case Mod - In Progress Ultra X-Blaster - New Design Idea [NEW PICTURES]

Discussion in 'Project Logs' started by UltraModder, 23 Mar 2009.

  1. UltraModder

    UltraModder Play Hard!

    Joined:
    23 Mar 2009
    Posts:
    82
    Likes Received:
    0
    Well I've been looking at some peoples modded cases and I've decided to do some modding while I have my case part for paint due to 3 deep scratches on the backside of the case. I know they wont be in view but I still want to get it all fixed. Going to be cutting out some holes in the motherboard tray for better wire management. In the future when I start to get my other HDD's and video cards I am going to add on to the botom of the case for more room. Im going to move the HDD cage to the newly added space when I make it or have it made at a shop i know of that does laser cutting and has a CNC bender. Going to also have a second PSU installed in the bottom for my SLI setup for better wire management and also the power supply i have now doesnt have many 6 pin connections for video cards.

    No water cooling for this new builder. Ill do that when I get more comforable with building and decide to tackle something harder in the future.

    I will also post a rendering of how the case will look like and will most likely be done in either MS Paint or photoshop.

    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]
    [​IMG]

    I know what some of you are thinking "Why are you using the old out of date IDE cables?"
    Well just to let you know I will be using all SATA connections when I get my HDD and DVD burner.

    I will have an update later this afternoon probably.
    Time to get out the drill dremel and sander! :thumb:

    Last edited: 3 Aug 2009
